SAS ODS Report Writing Interface: A Quick Demo

I personally nominated SAS ODS Report Writing Interface as one of the best technologies I found in SAS in 2012. It can generate reports cell by cell and row by row and provides a lot of flexibility to produce highly customized reports. Basically, to use it,

• first assign an ODS destination. Nothing new, and I prefer HTML like

ods html   file=”output.html” style=sasweb;

• then create a object(instance) based on the ODS Report Writing class, odsout,

declare odsout myout();

ODS Report Writing Interface holds some so-called object-oriented features. Odsout is a predefined class (or, a SET, a CONTAINER), then you take from it an instance or an object, myout(or any other legal SAS variable names). Suppose Odsout is a class for apples, then myout is a specific apple.

More Read

Leveraging Big Data and Analytics to Enhance Patient-Centered Care

Impressions of SAP HANA

Big Data After the Hype

How Tax Authorities May Use Big Data for Audits

Data Mining Helps Dropshipping Companies Discover Products

• apply methods associated with the Odsout class, like CELL, ROW, TABLE to generate reports.

Roughly methods are just the functions (subroutines, procedures) in the object oriented world. For example, in SAS Data Steps, you use function weight(apple) to get the weight of the apple; in object oriented world, you use apple.weight() to return the same thing. In ODS Report Writing Interface, if you want to get a table, use TABLE methods:

• myout.TABLE_START() to start a table
• myout.TABLE_END to end a table

Then all we need to do next is to use the flexible SAS data steps to leverage the ODS Report Writing Interface methods (see docs). The codes, you can see below, are pretty verbose compared to its counterparts, PROC REPORT, but that’s why it gains power to build highly customized reports. It’s also very structural (and easy to build, like playing blocks):

/*making a sortable HTML table*/
%macro ods_html_sort_table;



%mend;

title ;
ods listing close;
ods html   file=”a:\test\iris.html” style=sasweb headtext=”%ods_html_sort_table”;

data _null;
    set sashelp.iris;
    by Species;

/*    create an object, obj, based on the ODS Report Writing class, odsout*/
    if _n_ = 1 then do;
        dcl odsout obj();
    end;

    if (first.Species) then do; *by group processing;
       obj.title(text: “Fisher’s Iris Data Set by Species”); *title;

/*       start a table*/
       obj.table_start();
               obj.row_start();
              if (Species = “Setosa”) then
                 obj.image(file: “Iris_setosa.jpg” );*insert image;
              else if (Species = “Versicolor”) then
                 obj.image(file: “Iris_versicolor.jpg” );
              else if (Species = “Virginica”) then
                 obj.image(file: “Iris_virginica.jpg” );
            obj.row_end();

            obj.row_start();
                obj.format_cell(text: “Iris Species”,  overrides: “fontweight=bold just=right” );
                obj.format_cell(text: Species, column_span: 3, overrides: “just=left”);
            obj.row_end();

            obj.row_start();
                obj.format_cell(text: “Unit”,  overrides: “fontweight=bold just=right” );
                obj.format_cell(text: “(mm)”, column_span: 3, overrides: “just=left”);
            obj.row_end();
       obj.table_end();

       /* start another table */
       obj.table_start();
            obj.head_start();
                obj.row_start();
                    obj.format_cell(text: “Sepal Length” , overrides: “fontweight=bold”);
                    obj.format_cell(text: “Sepal Width” , overrides: “fontweight=bold”);
                    obj.format_cell(text: “Petal Length” , overrides: “fontweight=bold”);
                    obj.format_cell(text: “Petal Width” , overrides: “fontweight=bold”);
                obj.row_end();
            obj.head_end();
    end;

        obj.row_start();
            obj.format_cell(data: SepalLength);
            obj.format_cell(data: SepalWidth);
            obj.format_cell(data: PetalWidth);
            obj.format_cell(data: SepalLength);
        obj.row_end();

    if (last.Species) then do;
        obj.table_end();

        obj.note(data: “Note: These Tables are Sortable.”); *note;

        obj.foot_start(); *footer;
            obj.row_start();
                obj.cell_start();
                    obj.format_text(data: “Footer: Data from SAS V&sysver at &sysscp &sysscpl Sashelp.iris”,just:”C”);
                obj.cell_end();
            obj.row_end();
        obj.foot_end();

        obj.page();
    end;
run;

ods html close;
ods listing;

Note:

• A flavor added to get a sortable HTML report. Thanks to Charlie Huang and then Andrew Z to introduce a Javascript library JQury to SAS HTML report.
• The full report, see here.
• If column spannings needed, use the following codes as header (and the report here):

obj.head_start();
    obj.row_start();
        obj.format_cell(text: “Sepal” , overrides: “fontweight=bold”,column_span: 2);
        obj.format_cell(text: “Petal” , overrides: “fontweight=bold”,column_span: 2);
    obj.row_end();

    obj.row_start();
        obj.format_cell(text: “Length” );
        obj.format_cell(text: “Width” );
        obj.format_cell(text: “Length” );
        obj.format_cell(text: “Width” );
    obj.row_end();
obj.head_end();

• ODS Report Writing Interface will get rid of its preproduction hat since SAS 9.4, but you can use it somehow since SAS 9.1.3. For more, see the draft SAS 9.4 ODS documentation with ODS Report Writing Interface.
• To get started, see the developer’s paper.
