Modeling the MDM Blueprint – Part V
In this series we have discussed developing the MDM blueprint by creating Common Information (part II), Canonical (part III), and Operating (part IV) models in our work streams. We have introduced the Operating Model into the mix to communicate how the solution will be adopted and used to realize the benefits we expect with the […]
In this series we have discussed developing the MDM blueprint by creating Common Information (part II), Canonical (part III), and Operating (part IV) models in our work streams. We have introduced the Operating Model into the mix to communicate how the solution will be adopted and used to realize the benefits we expect with the business in a meaningful way. And hopefully set reasonable expectations with our business partners as to what this solution will look like when deployed.
Now it is time to model and apply the technical infrastructure or patterns we plan on using. The blueprint now moves from being computation and platform independent to one of expressing intent through the use of more concrete platform specific models.
After the initial (CIM, Canonical, and Operating models) work is completed then, and only then are we ready to move on to the computation and platform specific models. We know how to do this well – for example see Information service patterns, Part 4: Master Data Management architecture patterns.
At this point we now have enough information to create the reference architecture. One way (there are several) to organize this content is to use the Rozanski and Woods extensions to the classic 4+1 view model introduced by Philippe Kruchten. The views are used to describe the system in the viewpoint of different stakeholders (end-users, developers and project managers). The four views of the model are logical, development, process and physical view. In addition selected use cases or scenarios are used to demonstrate or show the architecture’s intent. Which is why the model contains 4+1 views (the +1 being the selected scenarios).
Rozanski and Woods extended this idea by introducing a catalog of six core viewpoints for information systems architecture: the Functional, Information, Concurrency, Development, Deployment, and Operational viewpoints and related perspectives. This is elaborated in detail in their book titled “Software Systems Architecture: Working with Stakeholders Using Viewpoints and Perspectives”. There is much to learn from their work, I encourage you to visit the book’s web site for more information.
What we are describing here is how MDM leadership within very large-scale organization can eventually realize the five key “markers” or characteristics in the reference architecture to include:
– Shared services architecture evolving to process hubs;
– Sophisticated hierarchy management;
– High-performance identity management;
– Data governance-ready framework; and
– Registry, persisted or hybrid design options in the architecture selected.
Recommended, this is an exceptional way to tie the technical models back to the stakeholders needs as reflected in the viewpoints, perspectives, guidelines, principles, and template models used in the reference architecture. Grady Booch said “…the 4+1 view model has proven to be both necessary and sufficient for most interesting systems”, and there is no doubt that MDM is interesting. Once this work has been accomplished and agreed to as part of a common vision, we have several different options to proceed with. One interesting approach is leveraging this effort into a Service Orientated Modeling Framework introduced by Michael Bell at Methodologies Corporation.
Service Orientated Modeling
The service-oriented modeling framework (SOMF) is a service-oriented development life cycle methodology. It offers a number of modeling practices and disciplines that contribute to a successful service-oriented life cycle management and modeling. It illustrates the major elements that identify the “what to do” aspects of a service development scheme. These are the modeling pillars that will enable practitioners to craft an effective project plan and to identify the milestones of a service-oriented initiative—in this case crafting an effective MDM solution.
SOMF provides four major SOA modeling styles that are useful throughout a service life cycle (conceptualization, discovery and analysis, business integration, logical design, conceptual and logical architecture). These modeling styles: Circular, Hierarchical, Network, and Star, can assist us with the following modeling aspects:
– Identify service relationships: contextual and technological affiliations
– Establish message routes between consumers and services
– Provide efficient service orchestration and choreography methods
– Create powerful service transaction and behavioral patterns
– Offer valuable service packaging solutions
SOMF Modeling Styles
SOMF offers four major service-oriented modeling styles. Each pattern identifies the various approaches and strategies that one should consider employing when modeling MDM services in a SOA environment.
– Circular Modeling Style: enables message exchange in a circular fashion, rather than employing a controller to carry out the distribution of messages. The Circular Style also offers a way to affiliate services.
– Hierarchical Modeling Style: offers a relationship pattern between services for the purpose of establishing transactions and message exchange routes between consumers and services. The Hierarchical pattern enforces parent/child associations between services and lends itself to a well known taxonomy.
– Network Modeling Style: this pattern establishes “many to many” relationship between services, their peer services, and consumers similar to RDF. The Network pattern accentuates on distributed environments and interoperable computing networks.
– Star Modeling Style: the Star pattern advocates arranging services in a star formation, in which the central service passes messages to its extending arms. The Star modeling style is often used in “multi casting” or “publish and subscribe” instances, where “solicitation” or “fire and forget” message styles are involved.
There is much more to this method, encourage you to visit the Methodologies Corporation site (Michael is the founder) and download the tools, power point presentations, and articles they have shared with us.
So, based on my experience we have to get this modeling effort completed to improve the probability we will be successful. MDM is really just another set of tools and processes for modeling and managing business knowledge of data in a sustainable way. Take the time to develop a robust blueprint to include Common Information (semantic, pragmatic and logical modeling), Canonical, (business rules and format specifications), and Operating Models to ensure completeness. Use these models to drive a suitable Reference Architecture to guide design choices in the technical implementation.
This is hard, difficult work. Anything worthwhile usually is. Why put the business at risk to solve this important and urgent need without our stakeholders understanding and real enthusiasm for shared success? A key differentiator and the difference between success and failure on an MDM journey is taking the time to model the blueprint and share this early and often with the business. This is after all a business project, not an elegant technical exercise. Creating and sharing a common vision through our modeling efforts helps ensure success from inception through adoption by communicating clearly the business and technical intent of each element of the MDM program.
In the last part of the series I will be discussing where all this fits into the larger MDM program and how to plan, organize, and complete this work.
